Goods lift installed in Oxfordshire

Goods lift instaled in Oxfordshire Goods lift installed in Oxfordshire

Goods Lift, through floor with maximum working load 450kg, enclosed in a self-supporting mesh shaft. The platform will be 1300mm x 1300mm and guarded 900mm high on the non-loading edges.

At the entrance to the lift at both levels there will be 2200mm high gates, which will be fitted with electrical interlocks to prevent the gates being opened unless the platform is docked at the appropriate level and prevent the lift being operated unless all gates are closed.

At the lower level a 500mm long fixed ramp will be provided to assist loading on to the 50mm deep platform. Power supply 2.2kw, 415 volt, three-phase and neutral supply is required terminated in an isolator at the lower level.

Control is via a hold to run, push button control station adjacent to the gates at both levels. Installation five weeks, for client at Granville Way,  Bicester, Oxfordshire , OX26 4UR
